Miscellaneous Accessories
Electronic Box
Part No. EBMfor connection of passive sensors to permanent flow meters
- For rough environments - IP 68
- For use in Ex-Zone 1
- With hang up bail
Technical Data
| Elektronic Box, Type EBM | |
|---|---|
| Protection | IP 68 (closed connectors) |
| Ex-Approval | II 2 G Ex ib IIB T4 Gb |
| Operating temperature | −20°C to+50 °C (+40 °C in Ex Zone 1) |
| Storage temperature | −30°C to +70 °C |
| Operating pressure | max. 1 bar |
| Cable lengths | 3, 10, 15, 20, 30, 50 or 100 m |
| Connection | wire end to connect transmitter NivuFlow 750 |
| Medium-contacting materials | Polyurethane, stainless steel 1.4571, PP |
Specifications subject to change.
Downloads
Technical Instructions | Correlation Sensors and external Electronic Box (Rev. 12)
Mounting Instruction | Correlation and Doppler Sensors (Rev. 08)
EU Declaration of Conformity | External Electronic Box EBM
EU Declaration of Conformity | "EX" External Electronic Box EBM
IECEx Certificate of Conformity Sensor Family Mini and Transit Time Sensors
EU-Type Examination Certificate Sensor Family Mini and Transit Time Sensors
